Me ntses noj Extruder tshuab



200 kg/h mini ntses pub pellet-ua tshuab





Kuv txaus siab rau cov khoom no





Covfeed extruder tshuab, tseem hu ua floating ntses pub extruder, yog siv los ua cov khoom noj tsiaj rau dev thiab miv, nrog rau cov noog, npua, qav, thiab ob qho tib si tog thiab ntab dej pub rau ntses. Nws yog ib qho kev pabcuam siab - thev naus laus zis tsim los ntes cov khw muag khoom noj tsiaj loj hlob tuaj.



Covntses pub pellet zaub mov ua tshuabFeem ntau yog siv pobkws, ntses hmoov, nqaij hmoov, thiab qee cov khoom noj ntxiv ua raw khoom. Los ntawm kev sib xyaw, extruding, roasting, thiab flavoring, nws tsim cov khoom noj tsiaj zaum kawg, uas yog vim li cas nws tseem hu ua aub zaub mov extruder.



me ntses noj pellet tshuab



Cov qauv thiab cov ntsiab lus tseem ceeb ntawm ib qho Screw Floating Fish Feed Pellet Tshuab







Khoom Parameters



Qauv	Peev xwm (kg / h)	Main lub cev muaj zog (kw)	Feeder lub cev muaj zog (kw)	Cutter lub cev muaj zog (kw)	Screw txoj kab uas hla (mm)	Tshuab loj (mm)	Qhov hnyav (kg)
DGP-40	40-50	5.5	0.4	0.4	φ40	1.36*1.3*0.85	320
DGP-60	120-150	15	0.4	0.4	φ60	1.36*1.33*0.86	420
DGP-70	200-250	18.5	0.4	0.4	φ70	1.36*1.33*0.86	550
PIB-80	300-350	22	1.5	0.55	φ80	2.3*1.7*1.4	720
PIB-90	400-450	30	1.5	0.55	φ90	2.3*1.8*1.4	1100
DGP-100	500	37	1.5	1.5	φ100	2*2.8*1.2	1500
DGP-120	600-700	55	1.5	1.5	φ120	2.2*2.9*1.2	1800
PIB-135	800-900	75	1.5	2.2	φ135	2.2*3.1*1.37	2000
PIB-160	1000-1200	90	2 2	2.2	φ160	2.3*3.15*1.38	2500
PIB-200	1800-2000	132	3	3	φ200	2.35*3.45*1.65	3200





Daim Ntawv Teev Npe ntawm hom qhuav ntab ntses zaub mov pellet extruder tshuab



Qauv	Fais Tsav	Diesel Cav	Ib leeg ntsia hlau	Twin Ntsia Hlau	Tswj Vaj Huam Sib Luag	Cutter Assembly	Cutter Slide Rail	Gearbox	Reducer	Khoom siv hauv tsev
DGP series qhuav hom floating ntses zaub mov pellet txiag tshuab	✅	❌	✅	❌	✅	✅	❌	✅	❌	Carbon Steel
Diesel Qhuav-Hom ntses pub Extruder	❌	✅	✅	❌	✅	✅	❌	✅	❌	Carbon Steel
LX series qhuav hom ntab ntses pub pellet ua zeb	✅	❌	✅	❌	✅	✅	✅	✅	❌	Carbon Steel
LX-S series Qhuav Hom floating ntses pub pellet extruder tshuab	✅	❌	✅	❌	✅	✅	✅	✅	❌	SUS 304
Twin ntsia hlau Dry Type dev noj pellet tshuab	✅	❌	❌	✅	✅	✅	✅	❌	(Nco*)	SUS 304



(Ceeb toom *): Reducer integrated nyob rau hauv lub stainless hlau vaj tse.





Qhov zoo:

1. Cov ntses me me pub- ua tshuab yog granule pub- cov khoom siv puffing, uas tuaj yeem tsim ntau hom paj, thiab cov pwm tuaj yeem kho raws li qhov xav tau.

2. Cov khoom yog nruab nrog ib tug zaus hloov dua siab tshiab ceev tswj teb tej cuab yeej ntawm lub qhov hluav taws xob, uas muaj peev xwm arbitrarily kho lub rotary ceev ntawm cov hniav los tswj qhov ceev thiab ntev ntawm kev txiav.

3.Tus nqi ntawm cov khoom siv hauv tsev nthuav dav yog 60% -80% qis dua tus nqi lag luam; cov khoom noj khoom haus nthuav dav uas tsim los ntawm lub tshuab no yog qhov zoo nkauj thiab zoo nkauj, ntab saum npoo dej rau ntau tshaj 12 teev yam tsis muaj dab tsi, thiab tsis txhob ua paug rau hauv dej kom txo tau cov kab mob ntses.

4.Cov khoom siv yooj yim puffing tshuab qauv tsim-hauv cov ntsia hlau, lub tes tsho ntev ntev, cov khoom siv spinning thiab txiav lub sijhawm ntev; Qhov kub thiab txias tuaj yeem hloov kho, thiab qhov tso zis torque tuaj yeem hloov kho, kom cov khoom ua los ntawm cov qib siab ntawm puffing thiab du nto.

5.Novel tsim, tshwj xeeb, qauv yooj yim, yooj yim rau nruab, yooj yim rau dismantle, yooj yim suav, yooj yim rau kev khiav lag luam. Lub tes tsho thiab cov ntsia hlau yog ua los ntawm kev hnav tshwj xeeb- tiv taus, siab - kub- cov khoom siv hlau alloy steel thiab cua sov- kho kom muaj qhov zoo ntawm kev hnav tsis kam thiab lub neej ntev.



Daim ntawv thov





Ornamental ntses pub extruders siv pob kws, soybean (taum ncuav mog qab zib) tsiaj scraps, thiab lwm yam raws li raw cov ntaub ntawv, thiab yog haum rau zus tau tej cov khoom noj nrog txawv tsiaj flavors, xws li dev, miv, ntses, noog, luav, cw, dev, miv, minks, hma, thiab lwm yam.
Lub tshuab pub extruder yog tsim rau cov neeg ua liaj ua teb thiab me thiab nruab nrab - cov chaw ua khoom noj loj. Cov khoom noj yog tsim kom zoo thiab du; nws ntab rau saum npoo dej yam tsis muaj dab dej ntau tshaj 12 teev, tsis muaj kuab paug hauv dej, thiab ua kom tsis muaj menyuam kom txo tau cov kab mob ntses.
